通信裝置的硬件描述
PLC與PC機之間實現通道，可使二者互補功能上的不足，PLC用于控制方面既方便又可靠，而PC機在圖形顯示、數據處理、打印報表以及中文顯示等方面有很強的功能。因此，各PLC制造廠家紛紛開發了適用于本公司的各種型號PLC與PC機通信的接口模塊。三菱公司開發的FX-232AW接口模塊用于FX2系列PLC與計算機通信。還有與以太網連接的接口模塊AJ71E71、與MAP網連接的接口模塊AJ71M51-S1、與FAIS MAP網連接的接口模塊AJ71M51M1等。不同的通信方式，有著不同的成本價格和不同的適用范圍。在此介紹一種通過PC機的RS-232口與PLC進行通信的實現方法。
FX2系列PLC的編程接口采用RS-422標準，而計算機的串行口采用RS-232標準。因此，作為實現PLC計算機通信的接口電路，必須將RS-422標準轉換成RS-232標準。
RS-232與RS-422標準在信號的傳送、邏輯電平均不相同。
RS-232采用單端接收器和單端發送器，只用一根信號線來傳送信息，并且根據該信號線上電平相對于公共的信號地電平的大小來決定邏輯的“1”（-3～-15V）和“0”（+3～+15V）；
RS-422標準是一種以平衡方式傳輸?shù)臉?biāo)準，即雙端發送和雙端接收，根據兩條傳輸線之間的電位差值來決定邏輯狀態。RS-422電路由發送器、平衡連接電纜、電纜終端負載和接收器組成。它通過平衡發送器和差動接收器將邏輯電平和電位差之間進行轉換
選用MAXIM公司的MAX202實現RS-232與TTL之間的電平轉換。MAX202內部有電壓倍增電路和轉換電路，僅需+5V電源就可工作，使用十分方便；選用MAX490實現RS-485與TTL之間的轉換。每片MAX490有一對發送器/接收器，由于通信采用全雙工方式，故需兩片MAX490，另外只需外接4只電容即可。
PLC的RS-422接口配接DB-25型連接器，而PC機一般用DB-9型連接器。硬件電路圖如圖1所示。
將RS-232的RS、CS短接，這樣對計算機發送數據來說，PLC總是處于就緒狀態。也就是說，計算機在任何時候都可以將數據送到PLC內。又由于DR、ER交叉連接，因此，對計算機接收數據來說，必須等待至PLC處于準備就緒狀態。
2通信裝置的軟件描述
2.1 FX2系列PLC與計算機之間通信協議
FX2系列PLC與計算機之間的通信采用RS-232標準，其傳輸速率固定為9600bps，奇偶校驗位采用偶校驗。數據格式如圖2所示。數據以幀為單位發送和接收。一個多字符幀由力所示的五部分組成，其中和校驗值是將命令碼ETX之間的的呢字符的ASCII碼（十六進制數）相加，取得所得和的低二位數。STX和ETX分別表示該字符幀的起始標起和結束標志。
