易賣工控網（news.tpt0.cn）提供”UTNH23A模塊卡件TOSHIBA”，產品詳情：品牌/廠家：TOSHIBA東芝、型號：UTNH23A、成色：全新、貨期：現貨 1天內發貨、保修：180天，更多產品詳情就上易賣工控網。

UTNH23A   ABB機器人伺服電機在修復多個故障時出現異常聲音或振動，如何處理？伺服接線：電源電纜、編碼器電纜、控制電纜和電纜是否損壞；檢查控制線附近是否有干擾源，是否與附近的大電流電力電纜平行或太近；檢查接地端子的電位是否突然變化，以確保良好的接地。伺服參數：如果伺服增益設置得太大，建議從一開始手動或主動調整伺服參數；確認速度響應濾波器的時間常數設置。初始值為0，您可以測試以增加設置值；電子傳動比設置得太大，因此建議恢復到出廠設置；伺服系統和機械系統共振，測試和調整陷波濾波器的頻率和振幅。機械系統：連接電機軸和設備系統的聯軸器偏離，安裝螺釘未擰緊；滑輪或齒輪嚙合不良也會導致負載扭矩變化。測試空載運行。如果空載運行時正常，檢查機械系統的組合部分是否異常；識別負載慣性、扭矩和速度是否過大，并測試空載運行。如果空載運行正常，應降低負載或更換容量較大的驅動器和電機。Bently 3500在鋼鐵、電力、化工和石化行業中的應用及振動監測測點





壓縮機屬于通用設備類，較好地應用于鋼鐵、電力、冶金、化工、石化等企業。以下是電機通過齒輪箱驅動壓縮機組時使用的Bentley振動保護系統的配置示例，供您參考。





壓縮機組：電機、齒輪箱、壓縮機





Bently 3500的典型振動測量點布置如下：





電機的前后軸承箱配備有殼體振動傳感器，以測量電機軸承的j對振動。變速箱的低速端和高速端分別配備了殼體振動傳感器，以測量變速箱的j對振動。壓縮機的前后X-Y方向渦流傳感器系統用于監測軸振動。此外，還使用一套渦流傳感器系統測量壓縮機軸位移，并使用一套渦電流傳感器系統測量和監控關鍵相位。振動監測產品的系統配置如下：





離心式壓縮機——汽輪機驅動





對于在危險區域工作的裝置，Bentley傳感器和監控系統應具有多機構批準裝置的選項。對在安全區域工作的裝置沒有要求。





1.測點配置要求





Keyphasor（鍵相器）：在相同速度下，壓縮機機組的每個軸系都配有一個鍵相器測量點；Bentley 3300XL系列渦流傳感器用于測量。





軸振動：每個滑動支承軸承在X/Y方向上配備一對軸振動測量點（彼此垂直安裝），由Bentley 3300XL系列渦流傳感器測量。





軸向位移：壓縮機組的每個推力軸承都配有雙冗余軸向位移測量點；Bentley 3300XL系列渦流傳感器用于測量。





軸承振動（可選）：每個滾動支承軸承配有兩個軸承振動測量點（水平和垂直安裝），由Bentley 330500系列Velomitor壓電振動速度傳感器測量。





齒輪箱殼體振動（如適用）：應在每個齒輪箱輸入軸和輸出軸的支撐軸承處提供一對X/Y方向殼體振動測量點；Bentley 330400系列壓電振動加速度傳感器用于測量。





超速保護（可選）：每個壓縮機組配備三個冗余超速保護測量點，由3300XL系列渦流傳感器測量。2.Bently 3500配置要求





每個關鍵壓縮機組均配備Bentley 3500框架；Bently 35003500/15電源模塊；





Bently 35003500/22M瞬態數據接口模塊；Bently 35003500/25鍵相器模塊





Bently Bently 35003500/42M監控模塊，用于軸振動、軸位移、軸承振動和外殼振動的上述測量點





（如適用），3500/53三重冗余監測模塊應用于超速保護監測測量點，每個監測通道（軸振動、

How to deal with the abnormal sound or vibration of ABB robot servo motor when it runs in repair of several faults?

Servo wiring:

Whether the power cable, encoder cable, control cable and cable are damaged; Check whether there are interference sources near the control line and whether they are parallel or too close to the nearby high current power cables; Check whether the potential of the grounding terminal changes suddenly to ensure excellent grounding.



Servo parameters:

If the servo gain is set too large, it is recommended to manually or actively adjust the servo parameters from the beginning; Acknowledge the setting of the time constant of the speed response filter. The initial value is 0, and you can test to increase the setting value; The electronic gear ratio is set too large, so it is recommended to restore to the factory setting; Resonance of servo system and mechanical system, test and adjust the frequency and amplitude of notch filter.



Mechanical system:

The coupling connecting the motor shaft and the equipment system deviates, and the mounting screws are not tightened; Poor engagement of pulleys or gears will also cause load torque changes. Test no-load operation. If it is normal during no-load operation, check whether the combination part of the mechanical system is abnormal; Recognize whether the load inertia, torque and speed are too large, and test the no-load operation. If the no-load operation is normal, reduce the load or replace the driver and motor with larger capacity. Application of Bently 3500 in steel, electric power, chemical and petrochemical industry and measuring points for vibration monitoring



The compressor belongs to the general equipment category, which is better used in steel, power, metallurgy, chemical, petrochemical and other enterprises. The following is a configuration example of Bentley vibration protection system used by the motor to drive the compressor unit through the gearbox for your reference.



Compressor unit: motor, gearbox, compressor



Typical vibration measuring points of Bently 3500 are arranged as follows:



The front and rear bearing boxes of the motor are equipped with shell vibration sensors to measure the j pair vibration of the motor bearings. The low speed end and gao speed end of the gearbox are respectively equipped with case vibration sensors to measure the j pair vibration of the gearbox. The front and rear X-Y direction eddy current sensor system of the compressor is used to monitor shaft vibration. In addition, a set of eddy current sensor system is also used to measure the compressor shaft displacement, and a set of eddy current sensor system is used to measure and monitor the key phase. The system configuration of the vibration monitoring product is as follows:



Centrifugal Compressor – Steam Turbine Drive



For units working in hazardous areas, Bentley sensors and monitoring systems should have the option of multi agency approval units. There is no requirement for the units working in the safe area.



1. Requirements for measuring point configuration



Keyphasor: each shafting of the compressor unit at the same speed is equipped with a Keyphasor measuring point; Bentley 3300XL series eddy current sensor is used for measurement.



Shaft vibration: each sliding support bearing is equipped with a pair of shaft vibration measuring points in X/Y direction (installed vertically to each other), which are measured by Bentley 3300XL series eddy current sensors.



Axial displacement: each thrust bearing of the compressor unit is equipped with double redundant axial displacement measuring points; Bentley 3300XL series eddy current sensor is used for measurement.



Bearing vibration (optional): each rolling support bearing is equipped with two bearing vibration measuring points (installed horizontally and vertically), which are measured by Bentley 330500 series Velomitor piezoelectric vibration velocity sensor.



Gearbox shell vibration (if applicable): a pair of X/Y direction shell vibration measuring points shall be provided at the support bearings of input and output shafts of each gearbox; Bentley 330400 series piezoelectric vibration acceleration sensor is used for measurement.



Overspeed protection (optional): each compressor unit is equipped with three redundant overspeed protection measuring points, which are measured by 3300XL series eddy current sensors. 2. Bently 3500 configuration requirements



Each key compressor unit is equipped with Bentley 3500 frame; Bently 35003500/15 power module;



Bently 35003500/22M transient data interface module; Bently 35003500/25 Keyphasor Module



Bently Bently 35003500/42M monitor module for the above measuring points of shaft vibration, shaft displacement, bearing vibration and shell vibration



(If applicable), 3500/53 triple redundant monitoring module shall be used for overspeed protection monitoring measuring points, and each monitoring channel (shaft vibration, shaft displacement and bearing vibration) shall be configured with two relay output channels; Bently Bently 3500 3500/32 (4-channel) or 3500/33 (16 channel) relay module is adopted, Bently Bently 3500 3500/92Modbus communication gateway is adopted



For units working in hazardous areas, 3500 monitor modules connected to field signals shall be equipped with built-in safety barriers; 3500/04 intrinsically safe grounding module shall be configured in the 3500 rack.



Centrifugal Compressor – Motor Driven



For units working in hazardous areas, Bentley sensors and monitoring systems should have the option of multi agency approval units. There is no requirement for the units working in the safe area.



1. Bently 3500's requirements on the configuration of measuring points for vibration monitoring of the unit



Keyphasor: each shafting of the compressor unit at the same speed is equipped with a Keyphasor measuring point; Bentley 3300XL series eddy current sensor is used for measurement.



Shaft vibration: each sliding support bearing is equipped with a pair of shaft vibration measuring points in X/Y direction (installed vertically to each other), which are measured by Bentley 3300XL series eddy current sensors.



Axial displacement: each thrust bearing of the compressor unit is equipped with double redundant axial displacement measuring points; Bentley 3300XL series eddy current sensor is used for measurement.



Bearing vibration: each rolling support bearing is equipped with two bearing vibration measuring points (installed horizontally and vertically), which are measured by Bentley 330500 series Velomitor piezoelectric vibration velocity sensor.



Bearing temperature (if applicable): each sliding support bearing and thrust bearing shall be equipped with bearing pad temperature measuring points; The working face and non working face of thrust bearing shall be equipped with temperature measuring points at the same time.



Gearbox shell vibration (if applicable): a pair of X/Y direction shell vibration measuring points shall be provided at the support bearings of input and output shafts of each gearbox; Bentley 330400 series piezoelectric vibration acceleration sensor is used for measurement.



2. Bently 3500 configuration requirements



Bently 3500 frame for each key compressor unit



Each Bently 3500 rack is configured with redundant 3500/15 power modules



3500/22M transient data interface module is configured in each Bentley 3500 rack;



For the above Keyphasor measurement points, the Bently 3500 rack of each unit is equipped with corresponding 3500/25 Keyphasor modules



The 3500/42M monitor module must be configured for the above measuring points of shaft vibration, shaft displacement, bearing vibration and shell vibration



(If applicable), the above bearing temperature measuring points need to be configured with corresponding 3500/60, 61 temperature monitoring modules, or 3500/62 process quantity monitoring modules



Each monitoring channel (shaft vibration, shaft displacement and bearing vibration) is equipped with two relay output channels of D-type; Use 3500/32 (4-channel) or 3500/33 (16 channel) relay modules



Each Bently 3500 rack is configured with a 3500/92Modbus communication gateway



For units working in hazardous areas, 3500 monitor modules connected to field signals shall be equipped with built-in safety barriers; 3500/04 intrinsically safe grounding module shall be configured in the 3500 rack.



screw compressor



For units working in hazardous areas, Bentley sensors and monitoring systems should have the option of multi agency approval units. There is no requirement for the units working in the safe area.



1. Bently measuring point configuration requirements



Keyphasor: each shafting of the compressor unit at the same speed is equipped with a Keyphasor measuring point; Bentley 3300XL series eddy current sensor is used for measurement.



Shaft vibration: each sliding support bearing is equipped with a pair of shaft vibration measuring points in X/Y direction (installed vertically to each other), which are measured by Bentley 3300XL series eddy current sensors.



Axial displacement: each thrust bearing of the compressor unit is equipped with double redundant axial displacement measuring points; Bentley 3300XL series eddy current sensor is used for measurement.



Bearing vibration: each rolling support bearing is equipped with two bearing vibration measuring points (installed horizontally and vertically), which are measured by Bentley 330500 series Velomitor piezoelectric vibration velocity sensor.



Bearing temperature (if applicable): each sliding support bearing and thrust bearing shall be equipped with bearing pad temperature measuring points; The working face and non working face of thrust bearing shall be equipped with temperature measuring points at the same time.



Gearbox shell vibration (if applicable): a pair of X/Y direction shell vibration measuring points shall be provided at the support bearings of input and output shafts of each gearbox; Bentley 330400 series piezoelectric vibration acceleration sensor is used for measurement.



2.3500 Configuration requirements



Each key compressor unit is equipped with Bentley 3500 frame



Each Bently 3500 rack is configured with redundant 3500/15 power modules



3500/22M Transient Data Interface Module (RJ45 Network Interface) is configured in each Bentley 3500 rack



For the above Keyphasor measurement points, the Bently 3500 rack of each unit is equipped with corresponding 3500/25 Keyphasor modules



The 3500/42M monitor module must be configured for the above measuring points of shaft vibration, shaft displacement, bearing vibration and shell vibration



(If applicable), the above bearing temperature measuring points need to be configured with corresponding 3500/60, 61 temperature monitoring modules, or 3500/62 process quantity monitoring modules



Each monitoring channel (shaft vibration, shaft displacement and bearing vibration) is equipped with two relay output channels of D-type; Use 3500/32 (4-channel) or 3500/33 (16 channel) relay modules



Each Bently 3500 rack is configured with a 3500/92Modbus communication gateway



For units working in hazardous areas, 3500 monitor modules connected to field signals shall be equipped with built-in safety barriers; 3500/04 intrinsically safe grounding module shall be configured in the 3500 rack. API618 reciprocating compressor



For units working in hazardous areas, Bentley sensors and monitoring systems should have the option of multi agency approval units. There is no requirement for the units working in the safe area.



1. Requirements for measuring point configuration



Multi event Keyphasor: A multi event Keyphasor runner MEW is installed at the drive end of the reciprocating compressor to measure the Keyphasor reference signal of the reciprocating compressor. The multi event Keyphasor runner can be Bentley standard multi event runner MEW, or the reciprocating compressor manufacturer can customize and design the multi event Keyphasor runner according to Bentley's engineering experience in multi event Keyphasor runner based on its own equipment structure design characteristics. The multi event Keyphasor signal is measured by Bentley 3300XL series eddy current sensor.



Crankcase vibration: a vibration speed sensor is arranged on the horizontal axis of each main bearing between two cylinder rows of the reciprocating compressor crankcase to measure the crankcase body vibration. Bentley 330500 series Velomitor piezoelectric vibration speed sensor is used when the working speed of the reciprocating compressor is higher than 500 rpm; Bentley 190501VelomitorCT piezoelectric vibration speed sensor is used when the working speed is lower than 500rpm.



Crosshead vibration: redundant acceleration sensors are configured on the vertical plane at the midpoint of crosshead movement of each cylinder of the reciprocating compressor to monitor the impact event of reciprocating components; Bentley 330425 acceleration sensor is used for measurement.



Piston rod position: a pair of mutually perpendicular piston rod position measuring points shall be configured in the horizontal and vertical directions of each cylinder of the reciprocating compressor perpendicular to the piston rod plane; Bentley 3300XL series eddy current sensor is used for measurement. For reciprocating compression piston rod measurement.



Cylinder dynamic pressure: each cylinder of the reciprocating compressor is equipped with two cylinder pressure measuring points (suction and exhaust), which are measured by Bentley 165855 cylinder pressure sensor.



Bearing vibration: each main bearing in the crankcase of the reciprocating compressor is equipped with a speed sensor to measure the bearing vibration. Bentley 330500 series Velomitor piezoelectric vibration speed sensor is used when the working speed of the reciprocating compressor is higher than 500 rpm; Bentley 190501VelomitorCT piezoelectric vibration speed sensor is used when the working speed is lower than 500rpm.



Bearing temperature: each main bearing is equipped with a temperature sensor to measure the bearing temperature.



Air valve temperature: each air valve (suction valve and exhaust valve) of the reciprocating compressor cylinder is equipped with a temperature measuring valve temperature.



Gearbox shell vibration (if applicable): a pair of X/Y direction shell vibration measuring points shall be provided at the support bearings of input and output shafts of each gearbox; Bentley 330,400 series piezoelectric vibration acceleration sensor is used for measurement.



Motor pad vibration: each rolling support bearing is equipped with two pad vibration measuring points (installed horizontally and vertically), which are measured by Bentley 330500 series Velomitor piezoelectric vibration velocity sensor.



2. Bently 3500 configuration requirements
In paper and board mills.. in a wide range of
the horizontal force component resulting from
converting operations... and in plants processing
web tension on a roll.
textiles, plastics, rubber or almost any web mate-
Several models and nominal loads are available
ial you can think of, you'll find ABB PillowBlock
in standard stainless steel constructions as well as
tension measurement systems.
in acid-resistant and mill- duty versions.
The performance of the PllowBlock load cells
The user-friendly digial signal-processing
is unsurpassed for applications characterized by
elecronics provides a high level of functionality to
heavy rll, high speeds and severe conditions - in cover a wide range of applications.
some instances they're the only viable option.
The key reason is the operating principle.
ABB Pillow Block load cells produce signals as a
result of magnetic change, which frees them from
the ineviable limitations and design compromises
of measurement technologies relying on some
form of physical movement.
The result is a load cell that combines srong,
low-impedance signal output with an exceedingly
stiff and rugged construction. A reliable, high-
performance load cell with exceptional resistance
to vibration, overloads, extreme temperatures and
otherwise harsh environments.
A complete PllowBlock measuring system
consists of appropriately sized load cells and a ten-
sion electronics. A junction box is sometimes used
to simplify the cabling and reduce cabling costs.
ABB offers two different types of PillowBlock
load cell: one design intended for conventional
vertical force measurement, and a second,
unique design that measures only


在造紙廠和紙板廠

水平力分量由

轉換操作…和廠內加工

卷筒紙張力。

紡織品、塑料、橡膠或幾乎任何網狀材料-

有幾種型號和額定負載可用

如果你能想到，你會發現ABB枕頭墊

標準不銹鋼結構以及

張力測量系統。

耐酸和研磨型。

PllowBlock稱重傳感器的性能

用戶友好的數字信號處理

對于具有以下特征的應用程序來說是無與倫比的

電子技術為

重型rll、高速和惡劣條件-適用范圍廣泛。

在某些情況下，它們是可行的選擇。

關鍵原因是操作原理。

ABB枕式塊稱重傳感器作為

磁性變化的結果

不合理的限制和設計妥協

測量技術依賴于

身體運動的形式。

結果是將srong，

低阻抗信號輸出

堅固耐用的結構?？煽俊⒏?

具有卓越電阻的高性能稱重傳感器

振動、過載、溫度和

否則環境惡劣。

完整的PllowBlock測量系統

由適當尺寸的稱重傳感器和十個-

視覺電子。有時使用接線盒

以簡化布線并降低布線成本。

ABB提供兩種不同類型的枕頭墊

稱重傳感器：一種設計用于傳統

垂直力測量，

獨特的設計，僅測量
The PressductorP difference
Like ABB's other load cells based on Pressductor
Technology, PillowBlock Load Cells rely on ectto-
magnetic changes in the transducer, not on physical
movement, to sense fluctuations in web tension.
The Pressductor" Technology operating principle
provides exceptional improvements in load cell
performance characteristics, including reliability
(notably absence of drif), durability, repeatabiliy,
and wider measurement range.
Machined from a solid block of steel, the
load cells are rugged and siff, affording high
overload protection as well as an extended mea-
surement range above the nominal capacity. And
they won't contribute to machine vibration, even
at high speeds.
Since the transducer action - the magnetic
flux - takes place inside a steel core, environmen-
tal factors like dirt or fluids can't degrade perfor-
mance and reliabiliy.
Furthermore, low transducer impedance - less
then a couple of ohms - helps eliminate suscep-
tibility to radio frequency and elecromagnetic
interference.

PressductorP差異

與ABB基于Pressductor的其他稱重傳感器一樣

技術，枕式稱重傳感器依賴ectto-

傳感器中的磁性變化，而不是物理變化

以感測卷筒紙張力的波動。

Pressductor“技術操作原理

在稱重傳感器中提供了卓越的改進

性能特征，包括可靠性

（特別是沒有drif）、耐久性、可重復性、，

以及更寬的測量范圍。

由實心鋼塊加工而成

稱重傳感器堅固耐用，應力強度因子高

過載保護和擴展mea-

額定容量以上的測量范圍。和

它們甚至不會導致機器振動

在高速下。

由于傳感器動作-磁性

通量-發生在鋼芯內部，環境-

污垢或液體等金屬因素不會降低性能-

性能和可靠性。

此外，傳感器阻抗低

然后幾歐姆-有助于消除suscep-

射頻和電磁兼容性

干擾
How the Measurement Signal Is Generated
Two commonly used transducer types - the strain
gauge and the LVDT transducer - rely on physi-
cal movement in the
transducer to produce a
measurement signal (see
Strain gange: Sretching alers drawings). Stretching，
reistance of ectrial circuits. compression or bending
motions are prerequisites for signal generation.
ABB's exclusive Pressductor Transducer produces
a signal as a result of changes in an electromagnetic
field. This operat-
ing principle has its
。
origin in a melallur-
8
gical phenomenon
according to which
mechanical forces
LVDT: Movement ofpiston causes
alter the capacity of
signal change in output coils.
some steels to convey magnetic flux.
Two perpendicular windings of copper wire around
a steel core combine to provide the transducers mea-
surement signal. A
magnetic field is created
in one of the windings,
sized so there is no
magnetic coupling
between them.
When the transducer
Pesductor Tecbmology:
is subjected to a force,
Mechanial fore alters mag the magneic feld pati-
netic. field.
tern changes. A por-
tion of the field couples with the second winding and
induces an AC vltage. This vltage - a comparatively
strong transducer signal that is proportional to the force
- is converted by the load cell system's electronics into
the system output.
Extended-Range
Designers appreciate...
Selecting and sizing load cells
Operation
V Remarkably high spring constant
Two types of ABB PillowBlock load cells are
An extended range
V Wide measurement range
designed for either conventional vertical force
of measurement
v High rliabiliy
measurement or to sense the horizontal force
beyond the nomi-
component that may arise as the processed mate-
nal load alows the
Operators value a load cell with...
rial partially wraps around a- measurement roll.
PillowBlocks to be
V No drift
Using the "horizontal" load cells can be quite
sized for normal, as
v No recalibration
advantageous. By design, they can be made excep-
opposed to maximum,
